Kursus ini merupakan kursus yang berfokus dalam modelling gedung baja dengan bantuan tekla structure. Peserta akan diajari mulai dari pengenaan user interface, membuat grids, modelling bagian struktur gedung sampai dengan penulangan, penghitungan volume otomatis sampai dengan export hasil kerja. Kursus ini juga merupakan series dari tekla structures yang mana lanjutannya adalah detailling struktur gedung baja. Jadi jangan sampai melewatkan kesempatan untuk belajar mulai dari modelling gedung baja terlebih dahulu.
|
Ahmad Rifqy Zein - BIM Engineer - Instruktur BIM PUPR x UNDIP |
Mahasiswa Teknik Sipil
Fresh Graduate Teknik Sipil
Dosen / Akademisi Teknik Sipil
Konsultan Teknik
Kontraktor
PU
dll
| Topik | Detail Silabus |
| Introduction to Tekla | a. Overview of Tekla b. Understanding Environment, Role and Configuration c. Create model and save the file d. Graphical user interface |
| Modelling in Tekla Basic | a. Tekla Structures basic tools and commands b. Use of Snaps and Level of detail in Tekla c. Insertion of Reference Models d. Grid generation in an example project in Tekla e. Creation of Levels in Tekla |
| Steel Modelling | a. Creation of Steel Columns in Tekla b. Creation of steel beam in Tekla – Single beam, polybeam, curved beam, twin profile, orthogonal beam c. Create plate, bent plate d. Welding e. Bolting |
| Assembly & part details | a. Modelling detail connection between steel parts b. Modifying and editing connection c. Understanding what is part and assembly details d. Assembly components e. Detecting and fixing clashes |
| Various type of connection | a. Base plate connection b. Column to beam moment connection c. Column to beam shear connection d. Beam to beam shear connection e. Stair |
| Numbering & detailing | a. Detailing views b. Generation of 2D drawings plans, elevations and detail views c. Numbering of main parts and assembly parts d. Single Part drawings and assembly drawings |
| Managing Drawing | a. Revising and updating b. Working with templates c. Printing drawings d. Working with NC files |
| Quantity Take Off | a. Understanding detail bill of quantities b. Exporting BOQ files |
